Airframe

• Serial Number  D-8345
• AFTT 5,293.1
• Seats 4 Seats
• Damage History Gear retraction incident in 1983
• Hangared Yes
• Complete Original Logs Yes
• Located KETB
• Annual Inspection Due  08/31/24
• Txp / Static Check Due 08/31/25
• ELT Battery Due 08/31/25
• W&B (lbs) GW 3,600, EW 2,133.5, Useful 1,466.5, CG 80.49"

Avionics

• ADSB Garmin GTX345R I/O ADSB
• Audio Panel Garmin GMA 35 Remote 4-Place
• Autopilot Garmin GFC 500 Digital A/P w/ YD & GA switch
• Engine Management JPI EDM 900
• Digital Instruments Dual Garmin G5s HSI / Attitude Indicator

• GPS 1 Garmin GTN 750xi IFR WAAS GPS w/Telligence Voice Commands
• GPS 2 Garmin GNS 530W IFR WAAS GPS
• Intercom Garmin GMA 35 Remote 4-Place
• Transponder Garmin GTX 345R I/O ADSB
• Accessories Avionics Master Switch, Garmin Smart Glide, Garmin FlightStream 510, Electronics International VA-1A Volt/Amps Digital Gauge,  Beechcraft Digital Chronometer, Electric Trim

Aircraft Data - V35

• Dimensions Height 6 ft 6 in, Wing Span: 33 ft 5 in, Length: 26 ft 4 in, Cabin Height: 50 In, Cabin Width: 42 In, Cabin Length: 10 ft 1 in, Cabin Volume: 104 cu ft, Internal Baggage: 34 cu ft, Cabin Door:  37" Wide x 36" High
• Operating Weights Max Ramp Wt: 3,412 lbs, MaxT/O Wt: 3,400 lbs, Max Landing Wt: 3,400 lbs, Empty Wt : 2,259 Lb, Fuel Capacity: 74 Gal Usable (444 lbs), Useful Load: 1,141 Lb, Payload (Full 74 Gal Fuel: 697 lbs, Max Baggage Wt (lbs): 270, Volume 16.5 cu ft
• Wing Area/Loading Area 177.6 sf, Loading 18.8 lbs/sf w/o Tip Tanks, 19.7 lbs/sf w/ Tip Tanks

• Power Loading 11.9 lbs/hp w/o Tip Tanks, 12.28 lbs/hp w/ Tip Tanks

• Best Rate Of Climb 1,140 fpm
• Oil Capacity 12 Qt
• Fuel Capacity Gal Total (540 lbs), 74 Gal Usable (444 lbs), 104 Gal Usable w/ 15 Gal Tip Tanks (624 lbs), 114 Gal Usable w/ 20 Gal Tip Tanks (684 lbs)
• Service Ceiling 17,500 ft

Engine & Propeller

• Engine Continental IO-520-BA, S/N 232641-H, 285HP, 1,700 TBO, 359 SMOH
• Propeller McCauley 2-Blade, Model 2A36C23, 84 Inch, , Hub S/N 180019, 648 SPOH in 2018

Airframe Enhancements / Modifications

• Paint DuPont Imron White with Orange and Brown Accents (1979)
• Interior Beige leather seats and side panels with taupe carpeting
• Other 2-Blade Prop, Rosen Visors, Copilot Vent Window, Vert Card Compass, LED Landing Light, LED Strobes, Shoulder Harnesses, Walker Air Skeg, Strobes, Dual Yoke w/Dual PTT, USB Outlets, Polished Spinner, 15 Gal D'Shannon Tip Tanks, GAMIs, Reiff Engine Heater, Eagle Fuel Drains, Static Wicks, Chrome Step, Small Baggage Door, Top Strobe Beacon, Belly Rotating Beacon, Cabin Inlet Air Scoop, Cowl Plugs, Aileron Trim, Colored Control Knobs, USB Outlets
• Noteworthy Maintenance - see notable maintenance summary attached below

Performance - V35

• Distances T/O Ground Roll: 965 ft, Landing Distance: 647 ft, Takeoff Distance Over 50 ft Obstacle: 1,320, Landing Distance Over 50 ft Obstacle: 1,177 ft
• Performance  Normal Cruise: 176 kts, Rate of Climb: 1,140 fpm (SL)
• Speeds Max Speed Vne: 195 kts, Max Structural Cruise Vno:  165 kts, Flaps Ext Speed Vfe: 113 kts, Landing Gear Extension Vlg: 143 kts, Stall Speed Vs: 64 kts, Stall Speed Vso:  55 kts, Maneuvering Speed Va: 132 kts, Best Rate Of Climb Vy: 96 kts (1,140 FPM), Best Angle Vx: 77 kts, Cruise Climb: 107 kts
• Range 717 NM

Aircraft Location

West Bend Municipal Airport - KETB
West Bend, Wisconsin  USA
